VB Series

Vortexx™ Series B

Up to 100,000 Surge Amp Capacity Single Phase Surge Protection

Main panel, subpanel and point of use applications up to 200 KAIC fault current rating. Status LED. 60,000 or 100,000 surge Amps available. NEMA 4X (IP65) indoor/outdoor rated enclosure.

  • UL 1449 5th Edition, Type 1
  • Imax: 60 kA per phase
  • Thermally fused metal oxide varistor suppression with added Gas Tube technology
  • Real-time per phase LED indicators and audible alarm
  • NEMA 4X (IP66) indoor/outdoor rated enclosure
  • In: 20 kA
  • Short Circuit Current Rating (SCCR) 200 kAIC
  • #12 AWG lead length: 18”
  • Designed to allow installation inside of electrical box
  • Lifetime warranty
  • Flush mount option
